For top-quality Suspension and Safety components, look to FK Bearings - Rod Ends and Jam Nuts, known for their superior Made in USA reputation. Don't risk using cheap China imitations, as they can cause catastrophic damage to your vehicle. Trust in the industry experts and choose FK Bearings for a secure and reliable build.

Right Hand Part Number	Left Hand Part Number	B DIA	D DIA	W WTH	T WTH	Ball DIA	A LGTH	N THD	C LGTH	a Mis Angle	ULT Static Radial Load	Approx Weight
		+.0025 -.0005	+.010 -.010	+.005 -.005	+.005 -.005	REF	+.015 -.015	UNF 3A	+.062 -.031	REF	(lbs)	(lbs)
JMX3T	JMXL3T	.1900	.625	.312	.250	.437	1.250	10-32	.750	13	2,855	.03
JMX4T	JMXL4T	.2500	.750	.375	.281	.500	1.562	1/4-28	1.000	16	5,262	.04
JMX5T	JMXL5T	.3125	.875	.437	.344	.625	1.875	5/16-24	1.250	14	7,640	.07
JMX6T	JMXL6T	.3750	1.000	.500	.406	.719	1.938	3/8-24	1.250	12	9,550	.11
JMX7T	JMXL7T	.4375	1.125	.562	.437	.812	2.125	7/16-20	1.375	14	10,290	.16
JMX8T	JMXL8T	.5000	1.312	.625	.500	.937	2.438	1/2-20	1.500	12	16,242	.25
JMX8-6T	JMXL8-6T	.3750	1.312	.625	.500	.937	2.438	1/2-20	1.500	12	16,242	.25
JMX10T	JMXL10T	.6250	1.500	.750	.562	1.125	2.625	5/8-18	1,625	16	17,959	.38
JMX12T	JMXL12T	.7500	1.750	.875	.687	1.312	2.875	3/4-16	1.750	14	28,090	.60
JMX14T	JMXL14T	.8750	2.000	.875	.687	1.312	3.375	7/8-14	1.875	12	55,690	.91
JMX14T-770	JMXL14T-770	.8750	2.000	.875	.770	1.375	3.375	7/8-14	1.875	12	45,051	.91
JMX16T*	JMXL16T*	1.000	2.950	1.375	1.015	1.875	4.500	1-1/4-12	2.500	17	107,182	2.74
JMX16-1T*	JMXL16-1T*	1.000	2.950	1.375	1.015	1.875	4.500	1-14	2.500	17	107,182	2.46
JMX20T*	JMXL20T*	1.2500	2.950	1.250	1.015	1.875	4.500	1-1/4-12	2.500	11	107,182	2.74
JMX24T*	JMXL24T*	1.5000	3.500	1.375	1.125	2.312	5.375	1-1/2-12	3.000	8.75	136,750	4.75
JMX32T**	JMXL32T*	2.0000	5.010	1.750	1.437	2.937	8.020	2-12	4.500	7.5	281,150	14.25

* TOLERANCE VARIATION FOR “D” & “A” ARE +/- .020

** TOLERANCE VARIATION FOR “D” & “A” ARE +/- .020 AND CHECK FOR AVAILABILITY
